Audionet SAM 20SE

7.490  incl. VAT 24%

Limited Edition
Celebrating Audionet’s legendary integrated amp’s 20 years anniversary we present the best SAM ever: the strictly limited SPECIAL EDITION SAM 20 SE (20th Anniversary).
An improved version of the classic  SAM who got the Class A Stereophile distinction for many years!

Clear

Description

A milestone in German amplifier construction:

New MOSFET power transistors with extremely low series resistance for a higher and more detailed fidelity in transient response (as used in the new worldwide benchmark WATT).
Extremely potent and acutely fast power supply, guaranteed by an encapsulated and cast-in 700 VA toroid transformer and new extremely low impedance and exceedingly fast audio-grade main capacitors with a 25% higher capacitance of 15,000 μF instead of 12,000 μF as before (total sum of 120,000 μF instead of 96,000 μF).

Further optimized inner wiring, all signal cables are made of silver and gold providing highest resolution and finest details.

New high grade mica capacitors in all places with crucial affect on sound. Their natural materials ensure a unique neutrality of sound.

Engraved front panel and re-designed back panel.

Dedicated SAM 20 SE Audionet metal remote control.

Inbuilt Phono card with the following improvements:

New integrated Op Amps of highest grade with extremely low-noise and fast FET inputs.
Optimized mica capacitors throughout. Their natural materials ensure a unique neutrality of sound.

Features

Strictly limited edition
Audionet ULA-Technologie (Ultra Linear Amplifier)
Completely DC-coupled, no capacitors in the signal path
Encapsulated toroid transformer with 700 VA
New audio-grade capacitors with 25% more filtering capacitance totalling 120,000 μF
New MOSFETs
New high grade mica capacitors in all places with crucial affect on sound
Onwards optimized gold-doped, pure silver, solid core signal cabling
Home cinema mode (bypass-mode) for easy home cinema integration
Microprocessor with its own power supply controls, handles all functions
Headphones output electronically switchable
Remote activation of other Audionet components via Audionet Link (optical fiber)
Included phono card with integrated OpAmps of highest quality and FET inputs as well as optimized mica capacitors
Engraved front panel and new back panel
Dedicated SAM 20 SE Audionet metal remote control
In- and Outputs
Audio inputs:
5 pair RCA line, gold-plated, teflon insulated
1 pair XLR balanced, gold-plated
Audio outputs:
1 pair RCA, gold-plated, teflon insulated (Pre-Out)
1 pair RCA, gold-plated, teflon insulated (Rec-Out)
6,3 mm jack plug for headphone (switchable)
Loudspeaker outputs:
2 pair Furutech Rhodium 4mm-jacks
Remote activation:
1 Audionet Link (out), optical



Case Color

, , ,

Specs

Technical Data

  • Output: 110 Watt into 8 Ω 200 Watt into 4 Ω
  • Filtering capacity: 120,000 μF
  • Damping Factor: > 1,000 at 100 Hz
  • Frequency Response: 0 – 500,000 Hz (-3 dB)
  • Harmonic Spectrum: k2 typ. -101 dB, @1kHz, 25 W/4 Ω k3 typ. -106 dB, @1kHz, 25 W/4 Ω
  • THD + N: < -100 dB @1kHz, 25 W/4 Ω
  • SNR: > 103 dB (A-weighted)
  • Channel Separation: > 93 dB @ 1 kHz
  • Input Impedance: Line-input: 10 kΩ, 150 pF XLR-input: 3 kΩ, 170 pF
  • Mains connection: 220..240 V / 50…60 Hz
  • Power Consumption: < 1 W stand-by, max. 700 W
  • Dimensions: width 430 mm height 110 mm depth 360 mm
  • Weight: 15 kg
  • Finish: Silver or Black with blue or red LED
